Additional information
| Weight | 3,03 kg |
|---|---|
| Reference number | 81511016313, 81511016315, 81511016328, 81511019315, 81511016315?, 81511016104, 81511016110, 81511016114, 81511016315 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.34 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.6 |
| Comments | Yoke rotated -30 deg |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Output force | 2203.13 lbf |
| Output force M | 2203.13 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 1.46 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 3.94 in |
| Type | 24 |
| Version | With Boot |
| Yoke | Ø14 |
| GTIN | 04057875163886 |
| Size (mm x mm x mm) | 200 x 140 x 200 |
| UPC | 193133247098 |
| Weight (kg) | 3.03 |
| Weight (lb) | 6.68 |
| Type of operation | Cam |
| Brand | WABCO |
