Additional information
| Weight | 3,306 kg |
|---|---|
| Reference number | A0074209624, 0074209624 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.464 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2023.28 lbf |
| Output force M | 2023.28 lbf |
| Port threads | M12 x 1.5 |
| Push-rod length | 2.13 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 5.18 in |
| Type | 24 |
| Version | With Boot |
| Yoke | Ø14H11 |
| GTIN | 04057875164050 |
| Size (mm x mm x mm) | 185 x 179 x 165 |
| UPC | 193133247548 |
| Weight (kg) | 3.306 |
| Weight (lb) | 7.2885 |
| Type of operation | Cam |
| Brand | WABCO |
