Additional information
| Weight | 3,478 kg |
|---|---|
| Reference number | 81511016516, 81511016516 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.34 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 5.2566 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2023.28 lbf |
| Output force M | 2023.28 lbf |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.57 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.72 in |
| Type | 24 |
| Version | With Boot |
| Yoke | Ø14H11 |
| GTIN | 04057875163268 |
| Size (mm x mm x mm) | 192 x 162 x 169 |
| UPC | 193133477891 |
| Weight (kg) | 3.478 |
| Weight (lb) | 7.6677 |
| Type of operation | Cam |
| Brand | WABCO |
