Additional information
| Weight | 6,47 kg |
|---|---|
| Reference number | 831026, 1517947 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 13.851 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Output force | 2989.96 lbf |
| Output force M | 2989.96 lbf |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | M16 x 1.5 |
| Return-spring force | 101.16 lbf |
| Stroke | 2.99 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 1.18 in |
| Total lenght | 6.14 in |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed |
| GTIN | 04057875161301 |
| Size (mm x mm x mm) | 270 x 270 x 190 |
| UPC | 193133244424 |
| Weight (kg) | 6.47 |
| Weight (lb) | 14.264 |
| Type | 36 |
| Brand | WABCO |
