Additional information
| Weight | 3,392 kg |
|---|---|
| Reference number | 1757305 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.34 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 8.46 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 psi |
| Output force | 1360.09 lbf |
| Output force 1 | 1573.66 lbf |
| Output force 2 | 1596.14 lbf |
| Output force M | 1360.09 lbf |
| Port threads | M16 x 1.5 |
| Ports | 30° |
| Push-rod length | 2.76 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Total lenght | 3.98 in |
| Type | 16 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | With |
| GTIN | 7895851056381 |
| Size (mm x mm x mm) | 197 x 197 x 218 |
| UPC | 193133245629 |
| Weight (kg) | 3.392 |
| Weight (lb) | 7.4781 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
