Additional information
| Weight | 2,763 kg |
|---|---|
| Reference number | 81511016080, 81511016249, 81511016260, 81511016274, 81511019249, 81511016249 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Clevis pin | 0.55 in |
| Comments | Yoke rotated 45 deg |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 116.0 psi |
| Output force | 1573.66 lbf |
| Output force M | 1573.66 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 1.46 in |
| Push-rod thread | M14 x 1.5 |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.57 in |
| Type | 16 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | Ø14 |
| GTIN | 04057875162636 |
| UPC | 193133245841 |
| Weight (kg) | 2.763 |
| Weight (lb) | 6.091 |
| Thread length | 0.79 in |
| Brand | WABCO |
