Additional information
| Weight | 2,952 kg |
|---|---|
| Reference number | 1379575, 0376963, 0591165, 591166 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.34 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 6.2346 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Output force | 1326.37 lbf |
| Output force M | 1326.37 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 3.35 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 5.00 in |
| Type | 16 |
| Version | Without boot |
| Yoke | Ø14H11 |
| GTIN | 04057875162735 |
| Size (mm x mm x mm) | 183 x 217 x 157 |
| UPC | 193133480112 |
| Weight (kg) | 2.952 |
| Weight (lb) | 6.508 |
| Type of operation | Cam |
| Brand | WABCO |
