Additional information
| Weight | 2,907 kg |
|---|---|
| Reference number | A0054209224, 0054209224, A0054209224 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 7.166 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Output force | 2225.61 lbf |
| Output force M | 2225.61 lbf |
| Port threads | M16 x 1.5 |
| Push-rod length | 3.78 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 3.94 in |
| Type | 20 |
| Version | With Boot |
| Yoke | Ø14 |
| GTIN | 04057875163152 |
| Size (mm x mm x mm) | 195 x 175 x 210 |
| UPC | 193133246381 |
| Weight (kg) | 2.907 |
| Weight (lb) | 6.409 |
| Type of operation | Cam |
| Brand | WABCO |
