Additional information
| Weight | 3,143 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Output force | 2630.27 lbf |
| Output force M | 2630.27 lbf |
| Port threads | Rc 3/8" (ISO 7-1) |
| Ports | 23° |
| Push-rod length | 2.32 in |
| Push-rod thread | M16 x 1.5 |
| Return-spring force | 55.08 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.37 in |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875164326 |
| Size (mm x mm x mm) | 154 x 209 x 248 |
| UPC | 193133247739 |
| Weight (kg) | 3.143 |
| Weight (lb) | 6.9291 |
| Type | 30 |
| Brand | WABCO |
