Additional information
| Weight | 3,986 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.54 in |
| Bolt threads | 5/8" – 11 UNC |
| Calculated Volume (dm³) | 1 |
| Clevis pin | 0.51 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.0 psi |
| Output force | 1483.74 lbf |
| Output force M | 1483.74 lbf |
| Port threads | 3/8" – 18 NPTF |
| Push-rod length | 3.55 in |
| Push-rod thread | 3/8" |
| Return-spring force | 44.96 lbf |
| Stroke | 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 4.17 in |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | With |
| GTIN | 04057875162827 |
| Size (mm x mm x mm) | 100 x 100 x 100 |
| UPC | 193133401513 |
| Weight (kg) | 3.986 |
| Weight (lb) | 8.788 |
| Type | 20 |
| Brand | WABCO |
