Additional information
| Weight | 1,624 kg |
|---|---|
| Reference number | A0044311612, 0044311612, 0054312512, 0044312512, 00543125, A0054312512, A0044311612 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 6.32 |
| Control pressure | 10 bar |
| Distance between bolts | 1.97 in |
| Exhaust | With silencer |
| Inlet Pressure | 147.9 psi |
| Max. operating pressure | 188.5 psi |
| Mounting | 2x M14 x 1.5 |
| Operational range | 0.5 to 4.5 bar |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port thread 41 | VOSS 232-NG 8 |
| Port thread 42 | VOSS 232-NG 8 |
| Range of adjustment | 7.25 to 65.27 psi |
| Regulating ratio | 1:5.3 |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| GTIN | 04057875226338 |
| Size (mm x mm x mm) | 270 x 154 x 152 |
| UPC | 193133315575 |
| Weight (kg) | 1.624 |
| Weight (lb) | 3.5803 |
| Technical specification | OE specification |
| Brand | WABCO |
