Additional information
| Weight | 1,575 kg |
|---|---|
| Reference number | ABRA061, 1402227 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 6.036 |
| Control pressure | 10 bar |
| Distance between bolts | 1.97 in |
| Exhaust | With silencer |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 188.5 psi |
| Mounting | 2x M10 |
| Operational range | 0.4 to 2.7 bar |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port thread 41 | M16 x 1.5 JED-388 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Range of adjustment | 5.80 to 39.16 psi |
| Regulating ratio | 1:5.3 |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| GTIN | 04057875226314 |
| Size (mm x mm x mm) | 263 x 151 x 152 |
| UPC | 193133315599 |
| Weight (kg) | 1.575 |
| Weight (lb) | 3.4723 |
| Technical specification | OE specification |
| Brand | WABCO |
