Additional information
| Weight | 1,724 kg |
|---|---|
| Reference number | 1506229, 10560, 006750, 156864, 2203005, 2203020, S4757145090, 58110450, 5811045, 505811045, 76934, 1111732, S4757145090, S4757145090, 2090020, 050036, INS0120002, 056836, 33651, 10557121 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 8.761 |
| Distance between bolts | 3.31×3.31 in |
| Important information | If you need to calibrate this Load Sensing Valve, please use our LSV-Calculator (<a href="https://www.wabco-customercentre.com/solutioncentre/s/article/Diagnostics-resource-centre?language=en_US" target="_blank">Click here</a> ) |
| Max. operating pressure | 174 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M16 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Port thread 41 | M12 x 1.5 |
| Port thread 42 | M12 x 1.5 |
| Port thread 43 | Test port |
| Regulating range | 10.15 to 68.17 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type of operation | Static |
| GTIN | 04057875225942 |
| Size (mm x mm x mm) | 312 x 195 x 144 |
| UPC | 193133444466 |
| Weight (kg) | 1.724 |
| Weight (lb) | 3.801 |
| Type | Pneumatic |
| Brand | WABCO |
