Additional information
| Weight | 1,752 kg |
|---|---|
| Reference number | 1518976, 1935108, 050036, 50036, WA4757145110 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 8.5955 |
| Distance between bolts | 3.31×3.31 in |
| Max. operating pressure | 174 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M16 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Port thread 41 | M12 x 1.5 |
| Port thread 42 | M12 x 1.5 |
| Port thread 43 | Test port |
| Regulating range | 10.15 to 88.47 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| GTIN | 04057875226079 |
| Size (mm x mm x mm) | 303 x 197 x 144 |
| UPC | 193133315315 |
| Weight (kg) | 1.752 |
| Weight (lb) | 3.8625 |
| Type of operation | Static |
| Brand | WABCO |
