Additional information
| Weight | 2,008 kg |
|---|---|
| Reference number | 1506231, 7076399, 99707007541, 51301, 167032, 9455410, 09455410, 1111733, 82521616032, 308057, 495166, 1506231, 1935110 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 5.8 psi |
| Calculated Volume (dm³) | 10.3194 |
| Comments | Static valve for trailers: Mineral oil control medium |
| Control pressure | 160 bar |
| Distance between bolts | 3.31×3.31 in |
| Important information | If you need to calibrate this Load Sensing Valve, please use our LSV-Calculator (<a href="https://www.wabco-customercentre.com/solutioncentre/s/article/Diagnostics-resource-centre?language=en_US" target="_blank">Click here</a> ) |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M16 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Port thread 41 | M12 x 1.5 |
| Port thread 42 | M12 x 1.5 |
| Regulating range | 290.08 to 2030.53 psi |
| Regulating ratio | 1:8 |
| Temperature range | -40°C to +80°C |
| Type | Hydraulic |
| Type of operation | Dynamic |
| GTIN | 04057875226031 |
| Size (mm x mm x mm) | 360 x 195 x 147 |
| UPC | 193133315438 |
| Weight (kg) | 2.008 |
| Weight (lb) | 4.4269 |
| Technical specification | OE specification |
| Brand | WABCO |
