Additional information
| Weight | 1,831 kg |
|---|---|
| Reference number | 5010260528 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.06 in |
| Break point | 11.6 psi |
| Calculated Volume (dm³) | 6.6863 |
| Comments | With test port, solenoid valve (DIN 72585-A1-3.1-SN/K1 connection) |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +30° |
| Cooling | Air |
| Distance between bolts | 1.97 in |
| Electrical connection | Bayonet DIN 72585-A1-3.1-SN/K1 |
| Exhaust | With silencer |
| Max. operating pressure | 188.5 psi |
| Mounting | 2x M10 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total stroke | -45° to +95° |
| Type | Mechanical |
| Type of operation | Dynamic |
| Voltage | 24 V |
| GTIN | 04057875226284 |
| Size (mm x mm x mm) | 234 x 182 x 157 |
| UPC | 193133315612 |
| Weight (kg) | 1.831 |
| Weight (lb) | 4.0367 |
| Regulating ratio | 1:5.3 |
| Brand | WABCO |
