Additional information
| Weight | 1,623 kg |
|---|---|
| Reference number | 1505360, 1505360, 5010260529, 5010525218 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 11.6 psi |
| Calculated Volume (dm³) | 6.902 |
| Control pressure | 10 bar |
| Distance between bolts | 1.97 in |
| Exhaust | With silencer |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 188.5 psi |
| Mounting | 2x M10 |
| Operational range | 0.5 to 4.7 bar |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port thread 41 | M16 x 1.5 JED-388 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Range of adjustment | 7.25 to 68.17 psi |
| Regulating ratio | 1:5.3 |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| GTIN | 04057875226291 |
| Size (mm x mm x mm) | 264 x 172 x 152 |
| UPC | 193133315568 |
| Weight (kg) | 1.623 |
| Weight (lb) | 3.5781 |
| Technical specification | OE specification |
| Brand | WABCO |
