Additional information
| Weight | 1,12 kg |
|---|---|
| Reference number | 6112KG-3527010, 8283974000, 8283977000, 82839770000, A0034297844, 1614201, 99708410125, 1115035600033, 1,11504E+12, 110242600, 60147888, 60147888, 3506500595, 0034297844, 81521506012, 82839770000, 5029914, 502991408, 81521506012, 81521506013, 81521506020, 0034297844, 60147888, 0034297844, 0044291244, A0034297844, 60147888, 81521506012, 110242600, 11017336, 81521506012, 3506-500595, 580 127 166 0, 82839770000, 6112KG3527020, WG8701362018, 1102426000, 352700021, 3527-00021 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.285 |
| Exhaust | M22 x 1.5 |
| Max. operating pressure | 145.04 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 41 | M22 x 1.5 |
| Port thread 42 | M22 x 1.5 |
| Predominance | 14.50 psi |
| Regulating ratio | 1:1 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Version | Pressure reduction |
| GTIN | 7895851076341 |
| Size (mm x mm x mm) | 99 x 103 x 126 |
| UPC | 193133313335 |
| Weight (lb) | 2.4692 |
| Weight (kg) | 1.12 |
| Brand | WABCO |
