Additional information
| Weight | 6,45 kg |
|---|---|
| Reference number | 41285077, 41285078, 41285079, 41285080, 41285081, 41285082, 5801335173, 5801414915, 5801414916, 5801414922, 5801414923, 5801414924, 41211262, 41211392 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Air dryer | 4324160020 |
| Back flow | 4.6 psi |
| Calculated Volume (dm³) | 18.142 |
| Closing pressure static 21 | 94.3 psi |
| Closing pressure static 22 | 94.3 psi |
| Closing pressure static 23 | 85.6 psi |
| Closing pressure static 24 | 85.6 psi |
| Comments | MCPV pressure sensor: Yes (DIN bayonet 72585, 7-pin) |
| Cut-out pressure | 152.29 psi |
| Electrical connection | DIN 72585 A1-2.1-1-Sn/K2 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| MCPV | 9347050220 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 108.78 psi |
| Opening pressure 22 | 108.78 psi |
| Opening pressure 23 | 108.78 psi |
| Operational range | 11.60 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 12 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Port thread 25 | M16 x 1.5 |
| Port thread 26 | M22 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Silencer | Elbow for PA tube connection |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875288985 |
| Size (mm x mm x mm) | 292 x 327 x 190 |
| UPC | 193133360476 |
| Weight (kg) | 6.45 |
| Weight (lb) | 14.22 |
| Opening pressure 24 | 108.78 psi |
| Brand | WABCO |
