Additional information
| Weight | 5,5 kg |
|---|---|
| Reference number | 112 458 980 0, DZ96189360000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Air dryer | 4324159060 |
| Back flow | 5.1 psi |
| Calculated Volume (dm³) | 21.51 |
| Closing pressure dynamic 21 | 87.0 psi |
| Closing pressure dynamic 22 | 87.0 psi |
| Closing pressure dynamic 23 | 87.0 psi |
| Closing pressure dynamic 24 | 87.0 psi |
| Comments | No MCPV pressure sensor |
| Cut-out pressure | 145 psi |
| Exhaust | Silencer 432 407 015 0 |
| Heating connection | Kostal M27 x 1 |
| MCPV | 9347141610 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 94.27 psi |
| Opening pressure 22 | 94.27 psi |
| Opening pressure 23 | 108.78 psi |
| Operational range | 10.15 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 23 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Silencer | Silencer 432 407 015 0 |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Variable Nominal Flow Rate | 16.00 – 35.00 (L/min) |
| Voltage | 24 V |
| GTIN | 04057875288930 |
| Size (mm x mm x mm) | 207 x 312 x 333 |
| UPC | 193133360384 |
| Weight (kg) | 5.5 |
| Weight (lb) | 12.13 |
| Opening pressure 24 | 94.27 psi |
| Brand | WABCO |
