Additional information
| Weight | 5,405 kg |
|---|---|
| Reference number | 59550 7C003 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Air dryer | 4324150610 |
| Back flow | 8.0 psi |
| Calculated Volume (dm³) | 20.9625 |
| Closing pressure dynamic 21 | 79.8 psi |
| Closing pressure dynamic 22 | 79.8 psi |
| Closing pressure dynamic 23 | 79.8 psi |
| Closing pressure dynamic 24 | 79.8 psi |
| Comments | No MCPV pressure sensor |
| Cut-out pressure | 137.79 psi |
| Electrical connection | DIN 72585 A1-2.1-1-Sn/K2 |
| Exhaust | Silencer 432 407 015 0 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| MCPV | 9347141530 |
| Max. operating pressure | 145.0 psi |
| Opening pressure 21 | 87.02 psi |
| Opening pressure 22 | 87.02 psi |
| Opening pressure 24 | 87.02 psi |
| Operational range | 11.60 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | 3/8" NPTF |
| Port thread 22 | 3/8" NPTF |
| Port thread 23 | 3/8" NPTF |
| Port thread 24 | 3/8" – 18 NPTF |
| Port thread 4 | M12 x 1.5 |
| Silencer | Silencer 432 407 012 0 |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Variable Nominal Flow Rate | 16.00 – 35.00 (L/min) |
| Voltage | 24 V |
| GTIN | 7895851071339 |
| Size (mm x mm x mm) | 325 x 300 x 215 |
| UPC | 193133360346 |
| Weight (kg) | 5.405 |
| Weight (lb) | 11.916 |
| Opening pressure 23 | 101.53 psi |
| Brand | WABCO |
