Additional information
| Weight | 6,01 kg |
|---|---|
| Reference number | S4430E0440 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Air dryer | 4324150550 |
| Back flow | 4.1 psi |
| Calculated Volume (dm³) | 19.163 |
| Closing pressure dynamic 21 | 72.5 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 72.5 psi |
| Comments | No MCPV pressure sensor |
| Cut-out pressure | 145 psi |
| Exhaust | Silencer 432 407 015 0 |
| Heating connection | Retrofittable |
| MCPV | 9347050100 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 94.27 psi |
| Opening pressure 22 | 94.27 psi |
| Opening pressure 23 | 94.27 psi |
| Operational range | 10.15 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 23 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 25 | M22 x 1.5 |
| Port thread 26 | M22 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Silencer | Silencer 432 407 015 0 |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| GTIN | 04057875288817 |
| Size (mm x mm x mm) | 312 x 332 x 185 |
| UPC | 193133360292 |
| Weight (kg) | 6.01 |
| Weight (lb) | 13.25 |
| Opening pressure 24 | 94.27 psi |
| Brand | WABCO |
