Additional information
| Weight | 6,2 kg |
|---|---|
| Reference number | 0005662806 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Air dryer | 4324150540 |
| Back flow | 4.1 psi |
| Calculated Volume (dm³) | 20.65 |
| Closing pressure dynamic 21 | 72.5 psi |
| Closing pressure dynamic 22 | 72.5 psi |
| Closing pressure dynamic 23 | 72.5 psi |
| Closing pressure dynamic 24 | 75.4 psi |
| Comments | No MCPV pressure sensor |
| Cut-out pressure | 145 psi |
| Electrical connection | DIN 72585 A1-2.1-1-Sn/K2 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| MCPV | 9347050100 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 94.27 psi |
| Opening pressure 22 | 94.27 psi |
| Opening pressure 23 | 87.02 psi |
| Operational range | 10.15 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 23 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 25 | M22 x 1.5 |
| Port thread 26 | M22 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Silencer | Silencer 432 407 015 0 |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Voltage | 24 V |
| GTIN | 04057875288848 |
| Size (mm x mm x mm) | 210 x 298 x 330 |
| UPC | 193133360308 |
| Weight (kg) | 6.2 |
| Weight (lb) | 13.67 |
| Opening pressure 24 | 108.78 psi |
| Brand | WABCO |
