Additional information
| Weight | 5,392 kg |
|---|---|
| Reference number | 0634169, 634169, 319184, 84511016011, 070247006, 70247006, 0634169, 40634169, 0634169 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 10.657 |
| Con-rod length | 1.81 in |
| Distance between holes | 3.25/4.92 in |
| Max. operating pressure | 145.0 psi |
| Mounting | 2 x M12 x 1.5 / 3 x M10 |
| Output force | 3372.14 lbf |
| Port thread 11 | M16 x 1.5 |
| Push-rod thread | R 0.3 in |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 36 |
| Version | Without console mounting |
| GTIN | 04057875161738 |
| Size (mm x mm x mm) | 231 x 198 x 233 |
| UPC | 193133001720 |
| Weight (lb) | 11.887 |
| Weight (kg) | 5.392 |
| Brand | WABCO |
