Additional information
| Weight | 7,845 kg |
|---|---|
| Reference number | G530880140020 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 26.01 |
| Cartridge type | Air System Protector M39 |
| Cut-out pressure | 181.30 psi |
| Electrical connection | DIN 72585 A1-2.1-Sn/K1 |
| Exhaust | JED-463-0 |
| Heating System | Yes |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Opening pressure | 188.55 psi |
| Operational range | 18.85 psi |
| Port thread 11 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | Tire inflation device M16 x 1.5 |
| Port thread 3 | JED-463-0 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Silencer | No (432 407 012 0 retrofittable) |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Voltage | 24 V |
| GTIN | 04057875173502 |
| Size (mm x mm x mm) | 370 x 370 x 190 |
| UPC | 193133260370 |
| Weight (kg) | 7.845 |
| Weight (lb) | 17.3 |
| Solenoid connection | Bayonet DIN 72585-A1-2.1-1-Sn/K1 |
| Brand | WABCO |
