Additional information
| Weight | 3,588 kg |
|---|---|
| Reference number | 1505966, ZG046000002, 1932679, 20409515, 3172999, 20393337, 3951837, 20410156, 20546790 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 7.0723 |
| Cartridge type | Desiccant Cartridge |
| Cut-out pressure | 174 psi |
| Exhaust | No (432 407 012 0 retrofittable) |
| Heater | 894 260 043 2 |
| Heating connection | HDSCS 2-Pole |
| Max. operating pressure | 188.5 psi |
| Operational range | 13.05+10.15 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 4/23 | M12 x 1.5 |
| Silencer | No (432 407 012 0 retrofittable) |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Size (mm x mm x mm) | 178 x 154 x 258 |
| UPC | 193133420644 |
| Weight (kg) | 3.588 |
| Weight (lb) | 7.9102 |
| GTIN | 04057875171102 |
| Brand | WABCO |
