Additional information
| Weight | 3,549 kg |
|---|---|
| Reference number | 81521026217, 81521026371 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 6.7713 |
| Cartridge type | Desiccant Cartridge |
| Cooling | Compressed air |
| Cut-out pressure | 181.30 psi |
| Exhaust | No (432 407 012 0 retrofittable) |
| Heater | 894 260 049 2 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Mounting | 30 |
| Opening pressure | 188.55 psi |
| Operational range | 15.95 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 4/23 | M12 x 1.5 |
| Silencer | No (432 407 012 0 retrofittable) |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Voltage | 24 V |
| GTIN | 04057875171751 |
| Size (mm x mm x mm) | 259 x 172 x 152 |
| UPC | 193133255871 |
| Weight (kg) | 3.549 |
| Weight (lb) | 7.8242 |
| Technical specification | OE specification |
| Brand | WABCO |
