Additional information
| Weight | 4,2 kg |
|---|---|
| Reference number | 8235-SRWABK118X, 6300-432413001R, 4324130010, WAB432413001R |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Back flow | 10.2 psi |
| Calculated Volume (dm³) | 9.431 |
| Cartridge type | Desiccant Cartridge |
| Comments | USA version, with 11 bar safety valve |
| Cut-out pressure | 114.58 to 130.53 psi |
| Exhaust | Snap-on contour |
| Heater | 894 260 046 2 |
| Heating connection | 280 METRI-PACK NR.1202 0599 |
| Max. operating pressure | 145.0 psi |
| Opening pressure | 185.65 psi |
| Port thread 21 | 1/2" – 14 NPTF |
| Port thread 3 | JED-463-0 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Voltage | 12 V |
| Size (mm x mm x mm) | 155 x 215 x 283 |
| UPC | 193133482109 |
| Weight (kg) | 4.2 |
| Weight (lb) | 9.259 |
| GTIN | 7895851076396 |
| Brand | WABCO |
