Additional information
| Weight | 4,489 kg |
|---|---|
| Reference number | 59551 8C510, 59550 8A012 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Back flow | 8.0 psi |
| Calculated Volume (dm³) | 10.332 |
| Cartridge type | Desiccant Cartridge |
| Cooling | Compressed air |
| Cut-out pressure | 137.79 psi |
| Heater | 894 260 049 2 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 145.0 psi |
| Mounting | 30 |
| Opening pressure | 145.04 psi |
| Operational range | 11.60 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Port threads | M22 x 1.5 |
| Silencer | No (432 407 012 0 retrofittable) |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Voltage | 24 V |
| GTIN | 04057875172253 |
| Size (mm x mm x mm) | 280 x 205 x 180 |
| UPC | 193133464471 |
| Weight (kg) | 4.489 |
| Weight (lb) | 9.8965 |
| Technical specification | OE specification |
| Brand | WABCO |
