Additional information
| Weight | 4,05 kg |
|---|---|
| Reference number | A0004301515, 99707007540, 0004301515, A0004301515, 390854 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 8.658 |
| Cartridge type | Desiccant Cartridge |
| Cut-out pressure | 145 psi |
| Exhaust | JED-463-0 |
| Max. operating pressure | 188.5 psi |
| Opening pressure | 210.31 psi |
| Operating pressure | 188.5 psi |
| Operational range | 10.15 psi |
| Port thread 11 | M22 x 1.5 |
| Port thread 12 | M12 x 1.5 (closed) |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M16 x 1.5 JED – 388 |
| Port thread 23 | Tire inflation device M16 x 1.5 |
| Port thread 3 | JED-463-0 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Silencer | No (432 407 015 0 retrofittable) |
| Temperature range | -40°C to +65°C |
| Unloader | No |
| GTIN | 7895851020474 |
| Size (mm x mm x mm) | 185 x 180 x 260 |
| UPC | 193133359807 |
| Weight (kg) | 4.05 |
| Weight (lb) | 8.9287 |
| Technical specification | OE specification |
| Brand | WABCO |
