Additional information
| Weight | 4,071 kg |
|---|---|
| Reference number | 1527583, 1527583, 30016600 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 11.704 |
| Cartridge type | Desiccant Cartridge |
| Cut-out pressure | 181.30 psi |
| Exhaust | SILENCER 4324070150 |
| Heating connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Opening pressure | 210.31 psi |
| Operating pressure | 188.5 psi |
| Operational range | 21.76 psi |
| Port thread 11 | M22 x 1.5 JED – 152 |
| Port thread 12 | M12 x 1.5 JED – 152 |
| Port thread 21 | M22 x 1.5 JED – 152 |
| Port thread 22 | M16 x 1.5 JED – 388 |
| Port thread 23 | Tire inflation device M16 x 1.5 |
| Port thread 24 | M22 x 1.5 JED – 388 |
| Port thread 4/23 | 1/4" – 18 NPTF |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Unloader | Yes |
| Voltage | 24 V |
| GTIN | 04057875288572 |
| Size (mm x mm x mm) | 308 x 200 x 190 |
| UPC | 193133359609 |
| Weight (kg) | 4.071 |
| Weight (lb) | 8.975 |
| Silencer | 432 407 015 0 |
| Brand | WABCO |
