Additional information
| Weight | 0,68 kg |
|---|---|
| Reference number | 445332075, 1524831, H0356D02001A0, 5006034256, 41211070, 5006143405, 41211070, 5006034256, 5006143405, 9472195055, 125726, 41027224, 42070065, 42123220, 42542734, ABRD758, 464139X401, 1524831, 1453761, 1934978, DZ95189583020, 464139X401 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.668 |
| Cooling | Air |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet DIN 72 585 A1-3.1-Sn/K1 |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port threads | M22 x 1.5 |
| Protection class | IP 69K DIN 40050 BL.9 |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 7895851086005 |
| UPC | 193133443353 |
| Weight (kg) | 0.68 |
| Weight (lb) | 1.4991 |
| Size (mm x mm x mm) | 116 x 57 x 101 |
| Brand | WABCO |
