Additional information
| Weight | 0,676 kg |
|---|---|
| Reference number | A0054294044, 3550310M01C01A, 500433554, 0054294044, A0054294044 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.87768 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet DIN 72 585 A1-3.1-Sn/K1 |
| Exhaust | Union Ø 13,6 |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port threads | M22 x 1.5 |
| Protection class | IP 68 / IP 69K EN 60529 / IEC 529 |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875219064 |
| Size (mm x mm x mm) | 138 x 106 x 60 |
| Weight (kg) | 0.676 |
| Weight (lb) | 1.4903 |
| UPC | 193133311287 |
| Brand | WABCO |
