Additional information
| Weight | 0,71 kg |
|---|---|
| Reference number | 1505209, 1155262, 8167404, 08167404, 8167404, 113959, 81524526014, ACHA979, 81524526014, 81524529014, 4721950090, 1155262, 8167404, 110293210, 11017625, 81524526014, 1505209 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.77256 |
| Comments | For use with connector 8945901512 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Protection class | IP 68 / 69K EN 60529 / IEC 529 |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875218807 |
| UPC | 193133311584 |
| Weight (kg) | 0.71 |
| Weight (lb) | 1.5653 |
| Size (mm x mm x mm) | 111 x 116 x 60 |
| Brand | WABCO |
