Additional information
| Weight | 0,705 kg |
|---|---|
| Reference number | AB4721950110, 0084275, 084275, 84275, 84275, 0084275, 1934973, 40084275, 0084275 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.759 |
| Comments | For use with connector 8945901512 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port threads | M22 x 1.5 JED-388 |
| Protection class | IP 68 / 69K EN 60529 / IEC 529 |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875218838 |
| UPC | 193133311591 |
| Weight (kg) | 0.705 |
| Weight (lb) | 1.5543 |
| Size (mm x mm x mm) | 109 x 116 x 60 |
| Brand | WABCO |
