Additional information
| Weight | 0,662 kg |
|---|---|
| Reference number | 6538771, 6576932, 6579421, 6579422, 445332007, 5004310018, 3453401300, P34534 01300, 1504901, 3550ZB6-001, 99707006699, 35503156S, S35503156S, 3550315-6S, S3550310-6S, S3550315-6S, 007292, YC442C219AA, 1417135900001, 1106936800030, 1106935600030, 1,41714E+12, TDAS4721950180, 39800-87020, 594207F000, 59420 7F000, 41027224, 4460000008, 8015515, DG477000030, 41027224, 4460000008, E4460000008, 5801091133, 1079666, 41211070, 42070065, 42123220, 42542734, 3506200CF24QZGBA, 3506200N5Q-AGO, 59420-7F000, S472-195-018-0, 0K87T43802, 35A0350010, 235600020, 35A03-50010, 502666708, 8235-S4721950180, 6300-4721950180, S4721950180, 13C0008804AA, 1504901, S472-195-018-0, 1376793, 1934975, 12992, 61223550112, DZ9100580213, WG9718360002, WG9718360002/1, WG97183600021, 1102963200, SWB563050059-2, 00132412, 10674229, 28210607900, 1079666, 41027224, 41211070, 42070065, 42123220, 42542734, WAB4721950180, 355000017, 3550-00017 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.76275 |
| Comments | Additionally required 8946011322 |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet DIN 72 585 A1-3.1-Sn/K1 |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Protection class | IP 69K DIN 40050 BL.9 |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 7895851007321 |
| UPC | 193133443278 |
| Weight (kg) | 0.662 |
| Weight (lb) | 1.4595 |
| Size (mm x mm x mm) | 64 x 118 x 101 |
| Brand | WABCO |
