Additional information
| Weight | 0,683 kg |
|---|---|
| Reference number | TDAS4721950940, S472-195-094-0, 8235-S4721950940, 6300-4721950940, S4721950940, S472-195-094-0, TDAS4721950940, WAB4721950940 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.69896 |
| Cooling | Air |
| Distance between holes | 2.8×0.79 in |
| Electrical connection | Bayonet DIN 72 585 A1-3.1-Sn/K1 |
| Exhaust | Flap |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | 1/2"-14 Dry seal NPTF |
| Port thread 2 | 1/2" – 14 Dry Seal NPTF |
| Port threads | 1/2'' – 14NPTF |
| Protection class | IP 66 / 69 K |
| Rated current | 2220 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 12 V |
| GTIN | 04057875219149 |
| UPC | 193133443445 |
| Weight (kg) | 0.683 |
| Weight (lb) | 1.5058 |
| Size (mm x mm x mm) | 117 x 103 x 58 |
| Brand | WABCO |
