Additional information
| Weight | 0,867 kg |
|---|---|
| Reference number | C00203901, 1610595, 7055966, 14195, 053670, TDAS4721950310, CF352791, C00203901, F002005, 5311-055, 167143, S472-195-031-0, 5815453, 58154530, 505815453, 349275, 1227786, 502815301, 8235-S4721950310, 6300-4721950310, S4721950310, A6000JD09160, 924301-00121, 1485699, 05695, 1505089, 1610595, S472-195-031-0, 5021170197, 2090052, 050091, 50091, INS0160098, 43614, 2S4721950310, 2S472 195 031 0, WAB4721950310, 1013110 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.5277 |
| Distance between bolts | 2.95×2.95 in |
| Electrical connection | Bayonet DIN 72585 A1-3.1-Sn/K1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4 x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M22 x 1.5 |
| Port thread 3 | Snap-on contour |
| Port thread 4 | M16 x 1.5 |
| Protection class | IP 66 / IP 69K |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 7895851028272 |
| Size (mm x mm x mm) | 103 x 103 x 144 |
| Weight (kg) | 0.867 |
| Weight (lb) | 1.9114 |
| UPC | 193133443292 |
| Brand | WABCO |
