Additional information
| Weight | 2,071 kg |
|---|---|
| Reference number | 1624254, 7064984, 14194, 011008, 167145, 5815328, 58153280, 1111635, N2524526001, 924301-00086, 1278076, 20096, 1624254, 5021170198, 1934976, 54573, 054573, 43209, 21150110057, 1013178 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.6799 |
| Comments | Adapter kostal M24x1: 2x 8946011322 |
| Distance between bolts | 2.76×1.38 in |
| Electrical connection | Bayonet DIN 72585 A1-3.1-Sn/K1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 3 x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | 3x M22 x 1.5 |
| Port thread 23 | 3x M22 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Port thread 4 | M16 x 1.5 |
| Protection class | IP 66 / IP 69K |
| Rated current | 1650 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875218951 |
| Size (mm x mm x mm) | 246 x 164 x 116 |
| UPC | 193133311768 |
| Weight (kg) | 2.071 |
| Weight (lb) | 4.5658 |
| Voltage | 24 V |
| Brand | WABCO |
