Additional information
| Weight | 2,358 kg |
|---|---|
| Reference number | C00203202, 1506760, 7118060, 71070, C00203202, GV66000010, GV66000010, 5818838, 5058188380, 505818838, 6501232, 4301161, 10170572, A05101398, 924301-00100, AIF1187, 1527244, 1738449, 1932574, 1002739, 79735, B3225-6798-0, WA4005000700 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.353 |
| Electrical connection | X1 = 8-Pole. X6 = 8-Pole. 2x Sensor Connector |
| Max. operating pressure | 188.5 psi |
| Port thread 1 | 2x M26 x 1.5 |
| Port thread 21 | 3x M16 x 1.5 |
| Port thread 22 | 3x M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Port thread 4 | M16 x 1.5 |
| Protection Class | IP 66 |
| System | 2S/2M |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Standard |
| Version | VCS II |
| Voltage | 24 V |
| GTIN | 7895851043152 |
| UPC | 193133154655 |
| Weight (kg) | 2.358 |
| Weight (lb) | 5.1985 |
| Size (mm x mm x mm) | 223 x 131 x 149 |
| Brand | WABCO |
