Additional information
| Weight | 0,492 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.49086 |
| Electrical connection | 8-Pole TYCO C-114-18375-1 |
| Max. operating pressure | 237.9 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.07 / 0.08 in |
| Port thread 11 | VOSS 8.12 Ø 0.24 in |
| Port thread 12 | VOSS 8.12 Ø 0.24 in |
| Port thread 21 | VOSS 8.12 Ø 0.24 in |
| Port thread 22 | VOSS 8.12 Ø 0.24 in |
| Rated current | 1 A |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3x 2/2 |
| Voltage | 12 V |
| GTIN | 04057875220268 |
| Size (mm x mm x mm) | 60 x 101 x 81 |
| UPC | 193133312550 |
| Weight (lb) | 1.0847 |
| Weight (kg) | 0.492 |
| Brand | WABCO |
