Additional information
| Weight | 2,688 kg |
|---|---|
| Reference number | A0012604863, 0012602063, 0012604863, A0012604863 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.3131 |
| Electrical connection | Bayonet DIN 72585-A1-3.1-Sn/K2 |
| Max. operating pressure | 145.04 psi |
| Nominal diameter | 4.9 mm |
| Port thread 13 | VOSS NG 8 |
| Protection class | IP69K / IP67 |
| Rated current | 530 mA |
| System | EPS II |
| Technical specification | OE specification |
| Temperature range | -25°C to +120°C |
| Type | 2 – Position |
| Voltage | 24 V |
| GTIN | 04057875158578 |
| Size (mm x mm x mm) | 164 x 111 x 182 |
| UPC | 193133479185 |
| Weight (kg) | 2.688 |
| Weight (lb) | 5.926 |
| Brand | WABCO |
