Additional information
| Weight | 0,308 kg |
|---|---|
| Reference number | A0004204171, 0004204171 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.00000099999999747524 |
| Electrical connection | EN 175301-803-A/ISO 4400 |
| Max. operating pressure | 152.29 psi |
| Multi Nominal diameter (From Port 1 to x) | 0.05 in |
| Nominal diameter | 1.2 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 JED – 388 |
| Protection class | IP 65 |
| Rated current | 300 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Normally Closed |
| Voltage | 24 V |
| GTIN | 7895851011991 |
| Size (mm x mm x mm) | 1 x 1 x 1 |
| UPC | 193133485452 |
| Weight (lb) | 0.67902 |
| Weight (kg) | 0.308 |
| Brand | WABCO |
