Additional information
| Weight | 1,35 kg |
|---|---|
| Reference number | A0044299144, 0044299144, A0044299144, 1935138 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.8275 |
| Comments | P2:P42 = 1:2 |
| Distance between bolts | 2.95×2.95 in |
| Electrical connection | Bayonet DIN 72585 1A-2.1-Sn/K2 |
| Max. operating pressure | 147.94 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 3 | Exhaust |
| Port thread 41 | M16 x 1.5 JED-388 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Port thread 43 | M16 x 1.5 JED-388 |
| Protection class | IP 66 / IP 69K |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | Voss 230 |
| GTIN | 7895851072534 |
| Size (mm x mm x mm) | 142 x 130 x 99 |
| UPC | 193133317838 |
| Weight (kg) | 1.35 |
| Weight (lb) | 2.9762 |
| Voltage | 24 V |
| Brand | WABCO |
