Additional information
| Weight | 1,058 kg |
|---|---|
| Reference number | 1315693, 1315693, 1935140 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.1925 |
| Distance between bolts | 2.95×2.95 in |
| Electrical connection | Bayonet DIN 72585 1A-2.1-Sn/K2 |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 3 | Exhaust |
| Port thread 42 | M16 x 1.5 JED-388 |
| Protection class | IP 6K7 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875229728 |
| Size (mm x mm x mm) | 148 x 149 x 109 |
| UPC | 193133317883 |
| Weight (lb) | 2.3325 |
| Weight (kg) | 1.058 |
| Brand | WABCO |
