Additional information
| Weight | 1,122 kg |
|---|---|
| Reference number | 81521806021, 81521806019, 0054293644, 0054293644, 54293644, A0054293644, 81521806021, 81521806021 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.1357 |
| Distance between bolts | 2.95×2.95 in |
| Electrical connection | Bayonet DIN 72585 1A-2.1-Sn/K2 |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 3 | Snap on contour JED-463-0 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Protection class | IP 6K6K / IP 6K9K |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875229759 |
| Size (mm x mm x mm) | 138 x 146 x 106 |
| UPC | 193133317890 |
| Weight (lb) | 2.4736 |
| Weight (kg) | 1.122 |
| Brand | WABCO |
