Additional information
| Weight | 1 kg |
|---|---|
| Reference number | 3454403460, 34544 03460, P34544 03460, 445400054A, 598507M000, 59850 7M000, 249870421211, 11018718, DZ95259364003, 1102305000, 30016299 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.7668 |
| Comments | P2:P42 = 1:1 |
| Distance between bolts | 2.95×2.95 in |
| Electrical connection | Bayonet DIN 72585 1A-2.1-Sn/K2 |
| Max. operating pressure | 147.94 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 3 | Exhaust |
| Port thread 42 | M16 x 1.5 |
| Protection class | IP 66 / IP 69 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875229704 |
| Size (mm x mm x mm) | 149 x 98 x 121 |
| Weight (kg) | 1 |
| Brand | WABCO |
