Additional information
| Weight | 0,23 kg |
|---|---|
| Reference number | 4342050500, 1205640, 0024297944, 42105690, A0024297944, 42105690, 0024297944, 1205640, 0024297944, A0024297944, 1205640, 42105690, 1505387, 1205640 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Turn |
| Actuation angle | 48° |
| Calculated Volume (dm³) | 0.3 |
| Comments | No locking function |
| Exhaust | M10 x 1 |
| Max. operating pressure | 145.0 psi |
| Mounting | M28 x 1.5 |
| Nominal diameter | 7.0 mm |
| Port thread 1 | M14 x 1.5 |
| Port thread 2 | M14 x 1.5 |
| Port thread 3 | M10 x 1 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2 |
| GTIN | 04057875176657 |
| Size (mm x mm x mm) | 120 x 50 x 50 |
| Weight (lb) | 0.50706 |
| Weight (kg) | 0.23 |
| Brand | WABCO |
