Additional information
| Weight | 0,328 kg |
|---|---|
| Reference number | 3454401630, 34544 01630, 1195522, 273032, 4731301, 81521706026, 8285032000, A6294290044, 04731301, 1195522, 4731301, 81521706026, 81521706026, 1195522, 4731301, A6294290044, 6294290044, 81521706026, 41195522 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuating range | 0.20 in |
| Actuation | Push (knob) |
| Calculated Volume (dm³) | 0.34628 |
| Comments | No locking function (kNob) |
| Exhaust | Via hole in body |
| Max. operating pressure | 145.0 psi |
| Mounting | M26 x 1.5 |
| Nominal diameter | 5.0 mm |
| Port thread 1 | M14 x 1.5 |
| Port thread 2 | M14 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2 |
| GTIN | 04057875176596 |
| Size (mm x mm x mm) | 135 x 57 x 45 |
| Weight (kg) | 0.328 |
| Brand | WABCO |
