Additional information
| Weight | 0,19 kg |
|---|---|
| Reference number | 0649246, 649246, 0642909, 1934913 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuating range | 0.49 in |
| Actuation | Push |
| Calculated Volume (dm³) | 0.2783 |
| Color | Red |
| Comments | No locking function |
| Exhaust | M12 x 1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | M26 x 1.5 |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M10 x 1 JED-152 |
| Port thread 2 | M10 x 1.0 JED – 152 |
| Port thread 3 | Exhaust |
| Stroke | 0.49 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2 |
| Size (mm x mm x mm) | 121 x 50 x 46 |
| UPC | 193133306412 |
| Weight (kg) | 0.19 |
| Weight (lb) | 0.41888 |
| GTIN | 7895851085923 |
| Brand | WABCO |
